Descripción técnica
Cuadro
Cuadro:
URS Premium Aluminium | Gravel+ Geometry | Internal Cable Routing | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle
Horquilla:
URS Carbon | Internal BRake & Hub Dynamo Cable Routing | Fender Mounts | Cargo Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Potencia:
#spec_stem
Manillar:
BMC RAB 03 | Ergo Top Shape | Compact Bend
Puños:
Seat
Tija de Sillín:
BMC RSP 03t
Sillín:
Selle Royal
Transmisión
Platos y Bielas:
SHIMANO GRX FC-RX600
Platos:
46-30T
Potenciómetro:
Cassette:
SHIMANO CS-HG50-10
Tamaño del cassette:
11-36T
Cadena:
SHIMANO CN-HG95
Desviador Delantero:
SHIMANO GRX FD-RX400
Cambio Trasero:
SHIMANO GRX RD-RX400
Manetas de Cambio:
SHIMANO GRX ST-RX400
Marchas:
2 x 10
Pedalier:
PF86 Bottom Bracket
Frenos
Pinzas de Freno:
SHIMANO GRX BR-RX400
Discos:
SHIMANO SM-RT64
Tamaño del disco:
160 / 160mm
Ruedas
Llantas:
PRD23 | 23mm
Bujes:
CL-712 (F) | RXC-1425 (R) | Thru-Axle
Neumáticos:
WTB Riddler | 45mm
Información Tubeless:
Información adicional
Paso de rueda:
45mm
Clasificación ASTM:
Level 2
Límite de peso del sistema:
120kg
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Rider Height | < 165 | 162-172 | 170-182 | 180-192 | >190 |
| Reach | 390 | 400 | 410 | 420 | 430 |
| Stack | 525 | 550 | 580 | 610 | 640 |
| Bar Drop | 130 | 130 | 130 | 130 | 130 |
| Bar Reach | 70 | 70 | 70 | 70 | 70 |
| Bar Rise | |||||
| Bar Sweep | |||||
| Bar Width | 420 | 420 | 420 | 440 | 440 |
| Base Bar Drop Flat Cockpit | |||||
| Base Bar Drop V-Cockpit | |||||
| Base Bar Reach Flat Cockpit | |||||
| Base Bar Reach V-Cockpit | |||||
| BB Drop | 69 | 69 | 69 | 69 | 69 |
| BB Drop (SLACK) | |||||
| BB Drop (STEEP) | |||||
| BB Height (SLACK) | |||||
| BB Height (STEEP) | |||||
| Chainstay | |||||
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 |
| LT | BB Drop (SLACK) | |||||
| LT | BB Drop (STEEP) | |||||
| LT | BB Height (SLACK) | |||||
| LT | BB Height (STEEP) | |||||
| LT | Chainstay | |||||
| LT | Fork Length | |||||
| LT | Fork Rake | |||||
| LT | Frame Size | |||||
| LT | Front Center (SLACK) | |||||
| LT | Front Center (STEEP) | |||||
| LT | Head Tube | |||||
| LT | HT Angle (SLACK) | |||||
| LT | HT Angle (STEEP) | |||||
| LT | Reach (SLACK) | |||||
| LT | Reach (STEEP) | |||||
| LT | Rider Height | |||||
| LT | Seat Tube | |||||
| LT | ST Angle @750mm Saddle Height (SLACK) | |||||
| LT | ST Angle @750mm Saddle Height (STEEP) | |||||
| LT | ST Angle Actual (SLACK) | |||||
| LT | ST Angle Actual (STEEP) | |||||
| LT | ST Angle Effective (SLACK) | |||||
| LT | ST Angle Effective (STEEP) | |||||
| LT | Stack (SLACK) | |||||
| LT | Stack (STEEP) | |||||
| LT | Stand Over Height (80 in Front of BB) | |||||
| LT | Stand Over Height (Lowest Point) | |||||
| LT | Top Tube (SLACK) | |||||
| LT | Top Tube (STEEP) | |||||
| LT | Wheelbase (SLACK) | |||||
| LT | Wheelbase (STEEP) | |||||
| ST | BB Drop (SLACK) | |||||
| ST | BB Drop (STEEP) | |||||
| ST | BB Height (STACK) | |||||
| ST | BB Height (STEEP) | |||||
| ST | Chainstay | |||||
| ST | Fork Length | |||||
| ST | Fork Rake | |||||
| ST | Frame Size | |||||
| ST | Front Center (SLACK) | |||||
| ST | Front Center (STEEP) | |||||
| ST | Head Tube | |||||
| ST | HT Angle (SLACK) | |||||
| ST | HT Angle (STEEP) | |||||
| ST | Reach (SLACK) | |||||
| ST | Reach (STEEP) | |||||
| ST | Rider Height | |||||
| ST | Seat Tube | |||||
| ST | ST Angle @750mm Saddle Height (SLACK) | |||||
| ST | ST Angle @750mm Saddle Height (STEEP) | |||||
| ST | ST Angle Actual (SLACK) | |||||
| ST | ST Angle Actual (STEEP) | |||||
| ST | ST Angle Effective (SLACK) | |||||
| ST | ST Angle Effective (STEEP) | |||||
| ST | Stack (SLACK) | |||||
| ST | Stack (STEEP) | |||||
| ST | Stand Over Height (80 in Front of BB) | |||||
| ST | Stand Over Height (Lowest Point) | |||||
| ST | Top Tube (SLACK) | |||||
| ST | Top Tube (STEEP) | |||||
| ST | Wheelbase (SLACK) | |||||
| ST | Wheelbase (STEEP) | |||||
| Fork Length | 410 | 410 | 410 | 410 | 410 |
| Fork Rake | 45 | 45 | 45 | 45 | 45 |
| Frame Size | |||||
| Front Center | 608 | 626 | 647 | 668 | 689 |
| Front Center (SLACK) | |||||
| Front Center (STEEP) | |||||
| Head Tube | 92 | 118 | 150 | 182 | 214 |
| Head Tube Angle | 70 | 70 | 70 | 70 | 70 |
| HT Angle (SLACK) | |||||
| HT Angle (STEEP) | |||||
| Pad Reach Flat Cockpit | |||||
| Pad Reach V-Cockpit | |||||
| Pad Stack Flat Cockpit | |||||
| Pad Stack V-Cockpit | |||||
| Reach (SLACK) | |||||
| Reach (STEEP) | |||||
| Rear Center | 430 | 430 | 430 | 430 | 430 |
| Saddle Height Range | |||||
| Seat Angle | 74 | 74 | 74 | 74 | 74 |
| Seat Tube | 430 | 445 | 475 | 505 | 540 |
| Seatpost Drop | |||||
| Seatpost Length | 350 | 350 | 350 | 350 | 350 |
| Seatpost Offset | 15 | 15 | 15 | 15 | 15 |
| ST Angle @750mm Saddle Height (SLACK) | |||||
| ST Angle @750mm Saddle Height (STEEP) | |||||
| ST Angle Actual (SLACK) | |||||
| ST Angle Actual (STEEP) | |||||
| ST Angle Effective (SLACK) | |||||
| ST Angle Effective (STEEP) | |||||
| Stack (SLACK) | |||||
| Stack (STEEP) | |||||
| Stand Over Height (80 in Front of BB) | |||||
| Stand Over Height (Lowest Point) | |||||
| Standover Height | 720 | 738 | 768 | 797 | 830 |
| Stem Angle | ±6 | ±6 | ±6 | ±6 | ±6 |
| Stem Length | 70 | 70 | 70 | 80 | 80 |
| Top Tube | 540 | 558 | 576 | 595 | 614 |
| Top Tube (SLACK) | |||||
| Top Tube (STEEP) | |||||
| Trail | 78 | 78 | 78 | 78 | 78 |
| Wheelbase | 1028 | 1047 | 1068 | 1089 | 1110 |
| Wheelbase (SLACK) | |||||
| Wheelbase (STEEP) |
